High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen

Place of Origin Shenzhen
Brand Name ROGIN
Model Number LCMA-RX101B-1000
Document LCMA-RX0101GB01-C100.pdf
Minimum Order Quantity 5
Price Price is negotiable.
Delivery Time 6-8 weeks
Payment Terms T/T, L/C
Supply Ability Spot adequacy

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name 10.1 Inch LCD Display Panel Size 10.1"
Resolution 1280*800 Brightness 1000 (Typ.)
Aspect Ratio 16:10 Active Area 216.96*135.6mm
Outline Dimension 229.46*149.1*7.7mm
Highlight

High Brightness 10.1 Inch LCD Display

,

10.1 Inch LCD Display Outdoor

,

1000 Nits LCD Advertising Screen
Leave a Message
Product Description

10.1 inch High Brirghtness LCD Display 1280*800 LVDS 1000nits

Product Advantage ?

1. Brightness customization 700-5000cd/m2.
2. Outdoor sunlight readable.
3. Low power consumption.
4. High uniformity up to 85% .
5. Long lifetime, 50K hours(Typ), up to 80K hours
6. Aluminium backlight structure with good heat dissipation.
7. Wide temperature range up to -30°C-80°C.
8. High shock resistance and high stability.

Product Application ?

1. Bus Station Signage Board.
2. Intelligent Charging Pile.
3.Outdoor Electronic News Reading Board.
4. Intelligent Express Cabinet.
5. Vending Machine.
6. Commercial Advertising Machine.
7. Attractions Information Inquiry Machine.
8. Community Information Board.
High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen 0 High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen 1 High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen 2 High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen 3

Specifications ?

LCMA-RX101B-1000

High Brightness 10.1 Inch LCD Display Outdoor 1280*800 LVDS 1000 Nits LCD Advertising Screen 4

  Brand   Rogin
  Series   High Brightness LCD Display
  Panel Size(inch)
   10.1
  Model
   LCMA-RX101B-1000
  Brightness
   1000
  Power Consumption (W)
  5.2
  Resolution
  1280*800
  Active Area
   216.96*135.6
  Overall Size
   229.46*149.1*7.7
  Viewing Angle
   80/80/80/80
  Interface Definition
   LVDS (1 ch, 6/8-bit)
  Backlight Type   WLED
  Contrast Ratio
   1000:1
  Aspect Ratio
   16:10
  Touch Panel   Without
  Operating Temperature
   -20~70℃



? Product catalog of high brightness LCD display.pdf...
